PVCFlex elastic Mg

2-ply PVC wall, grey

other versions

work. temperature:: 0 °C up to +85 °C
material:: - 2-ply PVC wall, reinforced by yarn; - spiral: plastic coated spring steel wire
properties:: - good resistance against oil, alcalis and acids; - smooth inside; - UV and ozone resistant; - very flexible and lightweight
application:: - domestic and industrial vacuum cleaner
delivery forms:: - Ø 25 bis 70 mm - 15 m/roll; - Ø 76 bis 160 mm - 10 m/roll; - colour: grey
on request:: - colour: black; - short lengths; - custom made: for example with connecting parts

inner ø at mm	outer ø at mm	bending radius at mm	working pressure at bar	vacuum at mm WS	roll length at m	article number	delivery time at days
25	31	25	1,700	4100	15	104-025-4G00	about 5-8
28	34	28	1,600	3600	15	104-028-4G00	about 5-8
32	38	32	1,500	3600	15	104-032-4G00	about 5-8
35	41	35	1,400	3100	15	104-035-4G00	about 5-8
38	44	38	1,400	3100	15	104-038-4G00	about 5-8
41	47	41	1,400	3100	15	104-041-4G00	about 5-8
44	50	44	1,300	2900	15	104-044-4G00	about 5-8
51	57	51	1,300	2900	15	104-051-4G00	about 5-8
60	66	60	1,300	2500	15	104-060-4G00	about 5-8
63	69	63	1,000	2500	15	104-063-4G00	about 5-8
70	76	70	0,900	2000	15	104-070-4G00	about 5-8
76	82	76	0,800	1800	10	104-076-4G00	about 5-8
80	86	80	0,700	1800	10	104-080-4G00	about 5-8
89	95	89	0,700	1700	10	104-089-4G00	about 5-8
102	108	102	0,600	1500	10	104-102-4G00	about 5-8
110	118	110	0,600	1500	10	104-110-4G00	about 5-8
114	123	114	0,600	1200	10	104-114-4G00	about 5-8
127	133	127	0,600	1100	10	104-127-4G00	about 5-8
150	158	150	0,550	1100	10	104-150-4G00	about 5-8
160	168	160	0,550	1000	10	104-160-4G00	about 5-8
all data at about +23 °C
